Technology Articles

2022-09 Passive Components PUI Audio, Inc.

[Sep 16 2022] RHK03W, RHK06W, RHK10W and RHD40W provide 3-40W output power respectively, with 3000VAC reinforced insulation and up to 90% conversion efficiency. 36-160VDC input voltage, which can cover 72V, 96V and 110V systems of railway power supply In order to achieve high insulation, the whole power module is coated with engineering plastics with high dielectric strength and high thermal conductivity to so ...

2022-09 Power OmniVision Technologies Inc

[Sep 15 2022] OmniVision released the compact 5V/2A step-down converter WD10721 Howell Group launched the 5V/2A step-down converter WD10721. This product has the characteristics of high efficiency, small size, light load mode support, etc. It is suitable for mobile phones, the Internet of Things, solid state drives and other compact intelligent devices. In addition to providing CMOS image sensor, touch and dis ...

2022-09 Semiconductors Toshiba Semiconductor and Storage

[Sep 15 2022] Toshiba Electronic Components and Storage Devices Co., Ltd. has introduced two new MOSFET products with small high allowable power consumption TSOP6F package to expand its product line. They are respectively 20V N channel "SSM6K824R" and - 30V P channel "SSM6J825R", which are suitable for applications such as consumer electronic equipment and industrial equipment motor control. " The new product ...

2022-09 Semiconductors Toshiba Semiconductor and Storage

[Sep 15 2022] Toshiba Electronic Components and Storage Devices Co., Ltd. introduced a type of optical relay "TLP3406SRHA" with 30V off state output voltage. This product is a new member of the voltage driven optical relay product line, with a maximum rated operating temperature of 125 ° C, and is packaged with S-VSON4T, which has one of the smallest surface mounting areas in the industry. This product line (i ...

2022-09 Semiconductors Torex Semiconductor Ltd

[Sep 15 2022] Terex Semiconductor Co., Ltd. has developed the 400nA PWM/PFM ultra-low consumption current boost DC/DC converter XC9145 series. With the ultra small package WLP-6-05 (1.08 x 1.28 x 0.4 mm), an ultra small real installed area of 5.4 x 6.7 mm can be achieved even if small coils and ceramic capacitors are installed externally (Figure 3). High standby efficiency can reduce the size and capacity of t ...

2022-09 Semiconductors Infineon Technologies

[Sep 15 2022] Infineon announced the launch of a complete power management solution to support Intel Sapphire Rapids processor (CPU) based computing servers. This new solution using "surface mount" technology integrates a variety of Infineon power management devices and technologies, including XDP digital multi-phase controller, OptiMOS integrated power level device and OptiMOS IPOL regulator, which can provid ...

2022-09 Semiconductors Analog Devices

[Sep 15 2022] The CN0534 5.8GHz Low Noise amplifier (LNA) receiver reference design from Analog Devices. The compact size of the circuit provides high-gain, reliable overpower monitoring and protection, which is an added advantage for applications facing low signal strength or small coverage in the 5.8 GHz ISM band. The Analog Devices CN0534 LNA receiver reference design is a high performance RF receiver syste ...

2022-09 Semiconductors ams

[Sep 14 2022] Ams announced the launch of the new PLT5 522EA_ Q green laser is suitable for horizontal measurement, scanning, biological science, point projection and other application scenarios. Compared with traditional red laser, it has higher brightness, more convenient use, more reliable and more cost competitive. The new laser adopts TO56 metal packaging, which is compatible with the commonly used drive ...

2022-09 Semiconductors TDK

[Sep 14 2022] TDK Group introduced a new B3202 * H/J series EPCOS MKP-Y2 film capacitor for interference suppression applications. Compared with the traditional model with a maximum operating temperature of 110 ° C, the maximum operating temperature of B3202 * H/J series reaches 125 ° C. The capacity range of the new series is 1nF to 1 µ F, the maximum rated voltage is 300V AC, and it can maintain a stable cap ...

2022-09 Semiconductors Toshiba Semiconductor and Storage

[Sep 14 2022] Toshiba Electronic Components and Storage Devices Co., Ltd. introduced a 40V N-channel MOSFET "SSM6K804R" for on-board equipment to expand the product line. The new product SSM6K804R is manufactured with a new process to achieve industry-leading low on resistance. The maximum on resistance is 18m Ω under 4.5V grid source voltage. In addition, the flat lead package improves chip installation capab ...

2022-09 Semiconductors Vishay

[Sep 14 2022] Vishay Intertechnology, Inc. announced that NTCS0603E3..... T and NTCS0805E3..... T series automotive grade glass package protection thermistors have expanded the overall dimensions of 0603 and 0805, and new resistance devices at+25 ° C (R25). The device complies with AEC-Q200 standard, and R25 resistance values include 1k and 1.5k low resistance values and newly added 5k resistance values, which ...

2022-09 Power Littelfuse

[Sep 14 2022] Littelfuse, Inc announced the launch of the new Pxxx0S3N SIDACtor Protective thyristor series, which can protect exposed interfaces in industrial and ICT applications, including RS-485 data interfaces and AC/DC power supplies. Protect equipment from severe transient over-voltage damage in harsh environments, and help designers meet regulatory requirements. Pxxx0S3N SIDACtor series adopts compact ...
