Technology Articles

2023-03 Power TE Connectivity

[Mar 24 2023] The AMP Micro CT connector is designed to provide an economical line routing solution for power or signal needs. These connectors provide impressive performance in their harness-making capabilities. AMP MicroCT connectors feature IDC terminals, discrete wire interconnects and AWG 26 to 28 cable sizes. These CT connectors offer a wide range of configurations, with circuits ranging from 2-25 single ...

2023-03 Power Taoglas

[Mar 24 2023] Taoglas Universe personal Computer. The Low-Profile SMD antenna is an active cellular and GNSS antenna designed for Internet of Things devices with small ground planes. PCS.60. The antenna combines aperture tuning and active switching technologies to provide broadband coverage for GNSS and most 5G/4G LTE cellular bands, including the challenging 600MHz to 700MHz bands. The antenna is easy to inte ...

2023-03 Optoelectronics Taoglas

[Mar 24 2023] The Taoglas Bolt A.85 Permanently Mounted antenna is a high-gain GNSS L1/L5 (GPS/GLONASS/Galileo/Beidou) antenna with a low profile, damage resistant design. The antenna has high out-of-band suppression and handles high-power bursts from nearby transmitters, allowing continuous operation. a. The 85 L1/L5 GNSS permanently mounted antenna uses an efficient patch antenna that optimizes performance w ...

2023-03 Semiconductors NXP

[Mar 24 2023] The NXP Semiconductor S32G Vehicle Network Processing Evaluation Board 3 is designed for vehicle service-oriented gateways (SOGs), domain control applications, high-performance processing, and safety and security applications. The evaluation board provides a combination of automotive and enterprise networking technologies that provide multiple interfaces to the vehicle network. The S32G eval boar ...

2023-03 Power Qorvo US Inc.

[Mar 24 2023] The Qorvo QPF4617 Wi-Fi 6E Nonlinear front-end module is designed for Wi-Fi 6E (802.11ax) systems. The Qorvo QPF4617 is designed to be used in conjunction with DPD correction. The device features a smaller contour size and integrated matching that minimizes application layout area. Performance is focused on optimizing the PA efficiency of the 5V supply voltage, minimizing power consumption. This ...

2023-03 Power ECS

[Mar 23 2023] ECS ECS-TXO-TX20CSMV4 MultiVolt Temperature Compensated Crystal Oscillator (TCXO) provides 1.7V to 3.6V MultiVolt capability and stabilizes critical applications using analog compensation. These shear sine wave SMD TCXOs are compatible with 1.8V, 2.5V, or 3.3V power supplies and offer frequency ranges from 10MHz to 52MHz, 10KΩ/10pF output loads, ±1ppm frequency tolerance, and ±0.5ppm or ±1.5ppm f ...

2023-03 Power ECS

[Mar 23 2023] The ECS ETXO-L33CL ECSpressCON Low Voltage Differential Signal (LVDS) temperature compensated Crystal Oscillator (TCXO) has low jitter, low current and a typical supply voltage of 3.3V. These surface mount oscillators are available in a frequency range of 10MHz to 1500MHz, with input currents of 25mA to 36mA, and package sizes of 3.2mm x 2.5mm x 1.6mm. Additional features include frequency config ...

2023-03 Semiconductors Analog Devices

[Mar 23 2023] Analog Devices AD4129-8 16-Bit Sigma-Delta Analog-to-Digital Converter (ADC) is an ultra-low power high-precision measurement solution for low bandwidth battery-operated applications. The fully integrated analog front end (AFE) includes a multiplexer for up to 16 single-ended or eight differential inputs, a programmable gain amplifier (PGA), and 16-bit sigma-delta (Σ-Δ) ADC, on-chip reference and ...

2023-03 Semiconductors Analog Devices

[Mar 23 2023] Analog Devices ADPA7002 power amplifier is a Gallium arsenide (GaAs), pseudocrystalline High electron mobility transistor (pHEMT), monolithic microwave integrated circuit (MMIC), 28dBm (1/2W) amplifier. A 6mm x 6mm ceramic leadless chip with a heat sink (LCC_HS) provides low thermal resistance and is compatible with surface mount manufacturing techniques. The ADPA7002 integrates a temperature com ...

2023-03 Semiconductors Microchip Technology

[Mar 23 2023] Microchip Technology AVR64EA48 Curiosity Nano Evaluation Kit (EV66E56A) is a hardware platform for evaluating AVR®EA family microcontrollers. The board is mounted with AVR64EA48 microcontroller. The board is supported by the MPLAB®X IDE and Microchip Studio for easy access to AVR64EA48's features to explore how the device can be integrated into custom designs. The Huggies Nano series evaluation B ...

2023-03 Power Maxim Integrated

[Mar 22 2023] Evaluation kit helps evaluate the TMC2210 stepper motor driver ic. The TMC2210-Eval-Kit consists of an MCU board Landungsbruecke, an Eselsbruecke, and a TMC2210-EVAL driver board. The toolkit provides a quick and easy start while supporting full access to all registers, functions, and diagnostics. All signals between the MCU and TMC2210 can be diagnosed by the probe on the bridge board. The TMC22 ...

2023-03 Optoelectronics Trinamic Motion Control GmbH

[Mar 22 2023] Trinamic TMC2210 stepper motor driver ic provides configuration options with encapsulated pins and additional diagnostic output. The TMC2210 integrates an advanced stepper motor driver based on a 256 microstep built-in indexer and two fully integrated 36V, 3.0A(Max)h Bridges as well as non-dissipative integrated current sensing (ICS). The Trinamic TMC2210 Stepper motor Drive ic features a Stealth ...
