Technology Articles

2023-01 Semiconductors Texas Instruments

[Jan 24 2023] The Texas Instruments THVD1424 RS-485 transceiver has on-chip 120Ω terminal resistance, swing rate control, and interchangeability between half-duplex and full-duplex modes. All characteristics are controlled by pins, so the device can be used at any node position (terminal node or intermediate node), 2-wire (half duplex) or 4-wire (full duplex), slow or fast in any network. The terminal device d ...

2023-01 Semiconductors Diodes Incorporated

[Jan 24 2023] Diodes Incorporated AP43776Q USB Type-C protocol decoder is a highly integrated dual channel PD3.1/PPS, BC 1.2, and QC protocol decoder. The protocol decoder supports 3.3V to 21V full range PPS APDO with 20mV/ step voltage resolution. The AP43776Q protocol decoder also supports up to 6A current with 50mA/ step resolution for power management. The protocol decoder has features such as E-Marker det ...

2023-01 Power Diodes Incorporated

[Jan 24 2023] Diodes AP22980 6V/6A low-RON power switches are a compact single-channel high-side power switch with flutter rate control, three-state soft start, and active output discharge path. The AP22980 contains an n-channel MOSFET that supports a maximum continuous current of 6A and operates in the input range of 0.285V to 5.5V. The device has a wide input voltage range and high current capability, so it ...

2023-01 Power STMicroelectronics

[Jan 24 2023] The STMicroelectronics STM32C0x Arm Cortex-M0+ 32-bit MCU uses a high performance Arm Cortex-M0+ 32-bit RISC core with operating frequency up to 48MHz. The device is highly integrated and ideal for a variety of consumer, industrial and appliance applications. In addition, these MCUS can be used in Internet of Things (IoT) solutions. The STM STM32C0x Arm Cortex-M0+ 32-bit MCU combines a memory pro ...

2023-01 Power STMicroelectronics

[Jan 23 2023] The STMicroelectronics STEVAL-IFP043V1 expansion board provides a powerful and flexible environment to demonstrate the IPS2050H dual high-end intelligent power solid state relay. IPS2050H is ideal for evaluating digital output modules connected to 2.5A(maximum) industrial loads. The STM Steval-IfP043V1 expansion board interfaces with the microcontroller on the STM32 Nucleo via a 5kV optocouplers ...

2023-01 Semiconductors Texas Instruments

[Jan 23 2023] The Texas Instruments TAS2783EVM Amplifier Evaluation Module (EVM) is designed to demonstrate the performance of the TAS2783 in a mono configuration. This design uses the onboard controller to provide a connection interface and provide voltage. The TAS2783 is a mono digital input Class d audio amplifier that efficiently drives peak power to a variety of speakers for a variety of audio application ...

2023-01 Semiconductors United Chemi-Con

[Jan 23 2023] The u-blox M2-JODY-W3 module is a card module that combines the performance of the JODY-W3 Wi-Fi 6 and Bluetooth 5.3 connection modules with the flexibility and ease of use of the M.2 card. The card supports the features of the JODY-W377 module and delivers the highest Wi-Fi data rates using the most advanced Wi-Fi 802.11ax technology. The device operates 2x2 MIMO at concurrent dual Wi-Fi (2.4GHz ...

2023-01 Power Recom Power

[Jan 23 2023] RECOM Power RSH3 3W Single/dual output DC/DC converters are high power density, surface mount, isolated DC/DC converters with no minimum load requirements. RSH3 converters have a 9V(DC) to 18V(DC) (RSH3-12X) or 18V(DC) to 36V(DC) (RSH3-24) input voltage range with single or double regulated outputs. Standard isolations are 2kV(DC)/1s, and 3kV(DC)/1s /H3 versions are available. The operating tempe ...

2023-01 Semiconductors STMicroelectronics

[Jan 23 2023] Stmicroelectronics IPS1025HFQ is a monolithic architecture of the M0T5 VIPower Technology, assembled in a QFN48L(8mm x 6mm) package. An IC is a single high-side switching device that can drive capacitive, resistive or inductive loads where one side is connected to the ground (high-side switching). The operating voltage is recommended to be between 8.65V and 60v, but the breakdown voltage on the p ...

2023-01 Power Diodes Incorporated

[Jan 23 2023] The AL1698K High Efficiency Dimmable LED driver is a high efficiency, high performance, high power factor, and high current accuracy boost, step-down boost, and flyback dimmable LED driver designed specifically for thyristor dimmable LED lamp applications. The AL1698K allows precise output current on integrated line and load regulation. The Boost topology enables device efficiency of more than 90 ...

2023-01 Semiconductors Texas Instruments

[Jan 22 2023] Texas Instruments BQ756506-Q1 Auto 6S Precision Battery monitor features high precision battery voltage measurement up to 6S battery modules. The device provides these measurements in less than 200 μs, while also supporting shunt resistance current sensing measurements. The integrated front-end filter allows the system to implement simple, low-voltage rated, differential RC filters on the cell in ...

2023-01 Power Traco Power

[Jan 22 2023] The TRACO Power TEL 15N and TEL 15WIN converters are 15W power converters with a power density of 4.51W/cm(3) in a pi-16 metal case only 0.94 "x 0.54" x 0.40 ". The TEL 15N series has a 2:1 input range, while the TEL 15WIN has a 4:1 input voltage range, and both series are available in radiator housing versions that support extended thermal performance to +70°C. These converters have a high effic ...
