Technology Articles

2023-01 Power XP Power

[Jan 26 2023] XP Power's unregulated IES02 converters, fixed input and isolated 2W DC-DC converters offer compact design and high efficiency. These isolated 2W converters also offer 1.5kV isolation, optional 3.0kV, short circuit protection and high operating temperature. IES02 2W converters are suitable for instrumentation and industrial applications. Reliable, cost-competitive 2W converters complement low-pow ...

2023-01 Power Allegro MicroSystems, LLC

[Jan 26 2023] Allegro MicroSystems A19351 Giant Magnetoresistance (GMR) AK Protocol Wheel speed/Direction sensor Integrated circuits (ics) are designed to measure ring magnets used in automotive braking systems. The A19351 integrated circuit provides wheel speed and direction information. The fully integrated circuit has a sensing element, a voltage regulator, an AD converter and a digital controller. These co ...

2023-01 Semiconductors NXP

[Jan 26 2023] The mc56f80, 000-evk Evaluation Suite is an ultra-low-cost development platform for the MC56F80x digital signal controller MCU family. It is externally compatible with ArduinoR3 pin layout. The evaluation kit board is a simple yet sophisticated design featuring the MC56F80748 DSC. The device combines the processing power of a digital signal processor (DSP) with the capabilities of a microcontroll ...

2023-01 Power Diodes Incorporated

[Jan 26 2023] Diodes Incorporated PI4IOE5V6416RQ The Diodes Incorporated PI4IOE5V6416RQ I/O expander is a 16-bit universal I/O expander that provides remote I/O expansion through an I2C bus interface for most microcontroller families. When additional I/O is required, the I/O extender provides a simple solution while minimizing interconnection. The PI4IOE5V6416RQ I/O extender has bidirectional voltage level con ...

2023-01 Semiconductors Diodes Incorporated

[Jan 25 2023] Diodes Incorporated AP62500 step-down converters have a wide input voltage range of 4.5V to 18V and 5A continuous output current. Available in 400kHz, 800kHz, or 1.2MHz switching frequency options, in V-QFN2030-12 (Type A) package. Fully integrated with a 47 Mω high-side power MOSFET and 18 Mω low-side power MOSFET, the AP62500 provides efficient step-down DC-DC conversion. The device uses consta ...

2023-01 Semiconductors STMicroelectronics

[Jan 25 2023] The STMicroelectronics STM32C03316-DK Discovery kit provides alternative features for the corresponding NUCLEO-C031C6 boards. Users can access the STM32C0 microcontroller's standard 20-pin layout. The user can override the SWD debug pin by disconnecting the debug probe. In addition, the 5-way analog rocker switch and LED can be replaced by the user using a sliding switch. The DIP28 connector supp ...

2023-01 Semiconductors STMicroelectronics

[Jan 25 2023] Designed for use in medium power quasi-resonant ZVS (zero voltage switch when switch on) flyback converters. It can provide output power up to 75W wide range, 100W European range, or front-end PFCS. The device integrates a complete set of features to provide an extremely flexible and easy-to-use chip that can help design efficient off-line power supplies. ZVS quasi-resonant operation has dynamic ...

2023-01 Semiconductors Texas Instruments

[Jan 25 2023] The Texas Instruments TPSI3050/TPSI3050-Q1 Enhanced Switch driver is an integrated device that comes in a SOIC 8-pin (DWZ) 7.50mm x 5.85mm package. When used in combination with an external power switch, it can constitute a complete isolated solid state relay (SSR). When nominal grid drive voltage is 10V and peak pull and fill currents are 1.5/3.0A, a variety of external power switches can be sel ...

2023-01 Semiconductors Texas Instruments

[Jan 25 2023] Texas Instruments TPS6287x-Q1 Synchronous step-down converters are a series of pin-to-pin step-down DC/DC converters with differential remote sensing capabilities for pin 6A, 9A, 12A and 15A. Each current rating is available in full-function device models with I2C interface and limited function device models without I2C interface. All devices are highly efficient and easy to use. Low resistance p ...

2023-01 Power Traco Power

[Jan 25 2023] The TRACO Power TIB 240-124-BCMU is a 240W battery control module designed to transform existing AC/DC power converters into fully functional uninterruptible power solutions. The TRACO Power TIB-BCMU is powered by an integrated microprocessor, and the battery controller module ensures that the connected 24VDC lead-acid battery remains fully charged. The device performs periodic impedance measurem ...

2023-01 Semiconductors Texas Instruments

[Jan 24 2023] Texas Instruments TLC6984 48x16 Matrix LED Display Driver is a highly integrated common cathode Matrix LED display driver with 48 constant current sources and 16 scanning FETs. TLC6983 drives 16 x 16 and 32 x 32 RGB LED pixels, three TLC6984 is capable of driving 48 x 48 RGB LED pixels, stacked four TLC6984 can drive 64 x 64 RGB LED pixels. To achieve low power consumption, the device uses a comm ...

2023-01 Semiconductors Texas Instruments

[Jan 24 2023] Texas Instruments TPS92620-Q1 Automotive LED driver is a dual-channel driver with a unique thermal management design that reduces device temperature rise. The TPS92620-Q1 linear driver is powered directly from an automotive battery and has a wide voltage range, capable of output up to 250mA of full current load per channel. An external shunt resistor is used to share the output current and dissip ...
