Technology Articles

2022-12 Power Delta Electronics/Cyntec

[Dec 18 2022] Delta Industrial Power features two AC/DC power families designed for medical and industrial applications; 600 W convection-cooled U-channel MU-600C and 1200 W 1U closed MEB-1K2A. Both product lines have 24 V or 48 V outputs, with universal AC inputs ranging from 85 V(AC) to 264 V(AC), and operating temperatures ranging from -20°C to +70°C(with full power, not dropping to +50°C). Other features i ...

2022-12 Semiconductors Texas Instruments

[Dec 18 2022] Texas Instruments' TLV314 series single - and dual-channel op-amps represent low power, general purpose op-amps. Rail-to-rail input and output fluctuations (RRIO) and low static current (150 μs usually at 5 V) combined with the wide bandwidth of 3 MHZ make this home very attractive for a variety of battery-powered applications requiring a good balance between cost and performance. In addition, th ...

2022-12 Power Texas Instruments

[Dec 18 2022] Texas Instruments' ISO772x devices are high-performance dual-channel digital isolators with 5000 V(RMS) (DW pack) and 3000 V(RMS) (D pack) isolation ratings compliant with UL 1577. These devices are also VDE, TUV, CSA and CQC certified. ISO772x devices provide high electromagnetic immunity and low emissions at low power consumption while isolating CMOS or LVCMOS digital I/ o. Each isolated channe ...

2022-12 Power MaxLinear, Inc.

[Dec 18 2022] MaxLinear's XR34350 has a wide 10 V RS-232 driver output that supports a wider range of RS-232 peripherals. The XR34350 includes an integrated cable terminal to reduce the number of components and save board space. It supports either full DB9 RS-232 or RS485/RS-422 serial protocols, allowing all three protocols to be used interchangeability on a single cable or connector without the need for addi ...

2022-12 Power Maxim Integrated

[Dec 18 2022] Maxim Integrated's MAX35104ETL+ is a system-on-a-piece (SoC) gas flowmeter designed as an analog front-end solution for the medical ventilator and ultrasonic gas flowmeter markets. The MAX35104ETL+ features a measurement accuracy of 700 ps and automatic differential Time of Flight (TOF), allowing simplified gas flow calculations. An early edge detection ensures measurement with consistent wave pa ...

2022-12 Power Broadcom

[Dec 17 2022] Broadcom's acu-250l is a single-channel 1 MBd optical coupler with an 11 mm SO8 footprint. The device has an insulating layer between the light-emitting diode and the integrated photon detector to provide electrical insulation between the input and output. Compared to conventional phototransistor couplers, photodiode bias and output transistor collector have separate connections, reducing base co ...

2022-12 Connectors Silicon Labs

[Dec 17 2022] Silicon Labs' EFR32 Flex Gecko Wireless soc combines a friendly MCU with highly integrated radio support for sub-GHz and 2.4GHz proprietary wireless protocols. Single-mode solutions deliver industry-leading energy efficiency, ultra-fast wake-up times, scalable power amplifiers, and integrated balun. These SOCs are well suited to proprietary modulation schemes, including OOK, Stereotyped FSK, ster ...

2022-12 Power Monolithic Power Systems Inc.

[Dec 17 2022] Monolithic Power Systems' MPM3632C is a step-down regulator module integrated with a synchronous rectifier power MOSFET, inductors, and three capacitors. The MPM3632C provides a very compact solution that requires only input and output capacitors for 3 a continuous output current, with excellent load and line regulation over a wide input range. The MPM3632C operates at a fixed 3mhz switching freq ...

2022-12 Semiconductors ON Semiconductor

[Dec 17 2022] ON Semiconductor's BDK-GEVK development kit, highlighted by RSL10, is a low-powered Bluetooth 5 SoC kit. The kit serves as a substrate for the Bluetooth Internet of Things Development Kit (B-IDK). A daughter card or mask that is compatible with the backboard can be connected via an Arduino connector or a PMOD connector. Multiple sensor and actuator daughter cards can be connected to the BDK-GEVK ...

2022-12 Semiconductors Analog Devices

[Dec 17 2022] ADI's ADP2164 and ADP2166 are synchronous step-down dc-dc regulators in compact LFCSP packages. The ADP2164 has an input voltage range of 2.7V to 6.5V and an output voltage of 4a. The input voltage of the ADP2166 is 2.7V to 5.5V, and the output is 5 A and 6 A respectively. Output voltage options include 3.3V, 2.5V, 1.8V, 1.5V, 1.2V and 1.0V Fixed output and adjustable options capable of supportin ...

2022-12 Semiconductors Analog Devices

[Dec 17 2022] The LT8645 and LT8646 from Analog Devices are 65v, 8 A synchronous step-down/step-down regulators. These regulators feature a silent switching architecture designed to minimize EMI/EMC emissions while providing high efficiency at high switching frequencies. The architecture includes the integration of bypass capacitors to optimize all of the fast current loops inside, and makes it easy to achieve ...

2022-12 Power Altech Corporation

[Dec 16 2022] Alorium Technology's Evo M51 is an FPGA-enhanced embedded module with a 32-bit Arm Cortex-M4 microcontroller and an Intel MAX 10 FPGA. The Evo M51 board meets the Adafruit feather specification for major stitching, connectivity and functionality. Since the Evo is designed as a embeddable module, the main I/Os is routed to through-hole holes as well as slotted holes along the edge of the board. Ev ...
