Technology Articles

2022-11 Power Traco Power

[Nov 15 2022] Tallysman's TW5390 multi-band (L1/L2), multi-constellation Integrated Global Navigation Satellite System (GNSS) receiver/antenna with an Inertial measurement unit (IMU) and an integrated L-band correction receiver is ideal for precise point positioning independent real-time dynamic technology (RTK). The TW5390 is capable of delivering accuracy of less than 6 cm to support the most demanding navig ...

2022-11 Power Panasonic

[Nov 14 2022] Panasonic's AMG88x543 Grid-EYE wide-angle infrared array sensor features a high resolution 8x 8 pixels, with a total of 64 pixels for temperature distribution. These 90° sensors provide a digital output I²C external interface for detecting heat presence, direction, and temperature values. The built-in lens has a wider viewing Angle of 90° and uses MEMS thermoelectric reactor technology and compac ...

2022-11 Semiconductors Texas Instruments

[Nov 14 2022] Texas Instruments TMUX6219 is a complementary metal oxide semiconductor (CMOS) switch in a single-channel SPDT configuration. The device can use a single power supply (4.5V to 36 V), dual power supply (± 4.5V to ±18 V), or asymmetric power supply (VDD: 5 V, VSS: -8 V). The device supports bidirectional analog and digital signals from VSS to VDD on the source (Sx) and drain (D) pins. TMUX6219 is e ...

2022-11 Optoelectronics MaxBotix Inc.

[Nov 14 2022] MB7850 XL-TankSensor-WRMA from MaxBotix is a unique combination of enhanced hardware and firmware that delivers top-notch performance inside the tank. MB7850 tank sensor is a low-cost liquid level monitoring sensor, which uses ultrasonic technology for non-contact transmission detection. Its unique design makes it an easy to use sensor for a variety of liquid level detection applications. The MB7 ...

2022-11 Power Analog Devices

[Nov 14 2022] The ADI ADE9430 is a high-precision, fully integrated multiphase power and power quality monitoring device. Excellent analog performance and digital signal processing (DSP) kernel can achieve accurate energy monitoring in a wide dynamic range. Integrated high-end benchmarks ensure low temperature drift and a maximum combined drift of less than ±25 ppm/°C across the channel, including a programmab ...

2022-11 Optoelectronics Amphenol Advanced Sensors

[Nov 14 2022] Ampleon's CLL3H0914L-700 and CLL3H0914LS-700 are 700 W internally pre-matched RF gallium nitride-silicon Carbide HEMT power transistors available in the frequency range from 0.9 GHz to 1.4 GHz. These devices offer excellent efficiency, heat resistance and robustness for both short and long pulse applications. The CLL3H0914L-700 and CLL3H0914LS-700 can withstand a load mismatch corresponding to VS ...

2022-11 Optoelectronics 3M

[Nov 14 2022] 3M's polycarbonate carrier tape can be used in a range of precision-manufactured designs and solutions to help minimize chip migration and cracking and help reduce pickup failures. The size of the carrier bag has decreased dramatically in less than a decade. With the growing demand for smaller, thinner components and multi-chip stacks, as well as the need for individual chip tracking, true succes ...

2022-11 Semiconductors Analog Devices

[Nov 13 2022] Analog Devices' MAX78002 is an AI MCU that enables neural networks to execute at ultra-low power, at the edge of the Internet of Things. The device comes in a 144 CSBGA, 12 mm x 12 mm, 0.8mm pitch package. And combines the most energy-efficient AI processing with Analog Devices' proven ultra-low power MCU. Hardware-based CNN accelerators enable battery-powered applications to perform AI reasoning ...

2022-11 Sensors Richtek USA Inc.

[Nov 13 2022] The RT1718S is a highly integrated TCPC controller in a WQFN-32L 4x4 package. Includes IEC-61000-4-2 ESD protection unit for CC/SBU/DP/DM. The RT1718S integrates multiple high-voltage protection switches from the high-voltage VBUS SBU1/SBU2/DP/DM, reaching adjacent pins. The AMR of the SBU OVP switch is 24V. The high voltage USB 2.0 switch also supports high voltage DCP and fast charging protocol ...

2022-11 Optoelectronics GC Electronics

[Nov 13 2022] GCT further expanded its USB product range with the introduction of the elevated USB Type-C socket USB4800.the surface mount USB4800 features 16 pins to meet USB 2.0 specifications for power and data, and is designed with a centerline 3.5 mm above the PCB surface. A potential advantage of the elevation is the ability to use components with less than 1.6 mm of space below the connector. In additio ...

2022-11 Semiconductors Microchip Technology

[Nov 13 2022] Designed for operation in harsh conditions and extreme environments, Microchip's PIC32MZ-W1 Wi-Fi® SoC and Module Series of Pictures delivers industrial-grade features, robust Wi-Fi connectivity, and advanced security. The series features PIC32MZ-W1, a high performance 200 MHz microcontroller (MCU) that integrates excellent low power Wi-Fi connectivity and high performance encryption acceleration ...

2022-11 Semiconductors TDK

[Nov 13 2022] TDK EPCOS B78302A series compact transformers with innovative E5 cores are suitable for ultrasonic applications. They consist of three types, with conversion ratios between 1:1:10.8 and 1:1:15.3. Depending on the type, these SMD transformers provide inductance values from 2 mH to 4 mH. They are suitable for frequencies from 50 kHz to 300 kHz. These AEC-Q200 compliant components are very compact i ...
