Technology Articles

2022-11 Power TDK

[Nov 10 2022] TDK Corporation's B3271xHx series are EPCOS thin film capacitors for DC link applications with high energy and power density. Capacitors are rated from 500 VDC to 1,600 VDC, providing capacitance values from 0.47 µF to 170 µF and suitable for maximum operating temperatures of +105°C. The rugged, self-healing, ROHS-compliant capacitor has a typical life of 95,000 hours at rated voltage and operati ...

2022-11 Sensors Taoglas

[Nov 10 2022] Taoglas' monopole antenna covers the 5G/4G band with an ISM compatible antenna and also comes with a FAKRA connector. Designed to deliver superior wideband efficiency, the direct installation of the FAKRA connector also provides the device with a stronger and more robust junction than the SMA equivalent connector, maintaining an effective connection even in environments involving high vibration o ...

2022-11 Power STMicroelectronics

[Nov 10 2022] STMicroelectronics EVL400W-80PL Demo board is a 12 V to 400W converter tailored to the typical specifications of AC/DC adapters, with a wide input power range, extremely low power consumption at light loads, and good average efficiency. It consists of a mother board for installing high-voltage power devices, a main control board for installing IC controllers L4985A and L6699, and a secondary cont ...

2022-11 Sensors Nuvoton Technology

[Nov 10 2022] Nuvoton's NuMicro M0A23 series 32-bit microcontrollers feature an Arm Cortex-M0 kernel in a compact package. It features highly flexible digital pin function allocation, abundant analog peripherals, operating temperature range from -40°C to +125°C, operating voltage from 2.4V to 5.5V, CAN 2.0B and LIN interface for robust communication. The NuMicro M0A23 series is targeted at high operating tempe ...

2022-11 Sensors Nuvoton Technology

[Nov 9 2022] Nuvoton's NuMicro ML56 series of low-power microcontrollers are built with a 1T 8051 core, embedded 64KB flash memory and 4KB SRAM, built-in touch-sensitive buttons, and LCD drivers running at frequencies up to 24MHz. In normal operation mode with low power operation, it can run below 100 µA/MHz. When the LCD panel is on, the power off current is less than 2 µA. The ML56 series has an operating v ...

2022-11 Semiconductors STMicroelectronics

[Nov 9 2022] The ISM330IS is in a system-level package with a 3-axis digital accelerometer and a 3-axis digital gyroscope, high performance mode for improved performance (power consumption only 0.59 mA), and support for alway on low power features. To achieve optimal sports results in industrial and Internet of Things solutions. The ISM330IS has full-scale acceleration ranges of ±2 g, ±4 g, ±8 g, and ±16 g, a ...

2022-11 Semiconductors STMicroelectronics

[Nov 9 2022] STMicroelectronics L3751 synchronous step-down controller has a wide input voltage range of 6 V to 75 V. Because the shortest on-off time is only 40 ns, it has an extremely high voltage conversion ratio in the switching frequency range (100 kHz to 1 MHz). Diode simulation (DEM) implements a pulse jump mode that maximizes efficiency at light loads, thereby providing controlled output voltage rippl ...

2022-11 Power ams

[Nov 9 2022] The 514 nm (± 1 nm) laser diode of ams OSRAM is a non customized standard product, which enables scientific and measurement equipment manufacturers to replace the argon ion laser traditionally used to generate 514.5 nm peak wavelength laser emission. PLT5 522FA_ Semiconductor lasers such as P-M12 are generally more cost-effective than argon ion lasers, with smaller volume, longer service life and ...

2022-11 Semiconductors STMicroelectronics

[Nov 9 2022] STMicroelectronics IPS1025HFQ is a monolithic architecture using M0T5 VIPower technology and QFN48L (8 mm x 6 mm) package. These ics are single high-voltage side switching devices that can drive capacitive, resistive, or inductive loads on one side of the ground (high-voltage side switches). The recommended operating voltage is in the range of 8.65V to 60V, but the breakdown voltage on the power ...

2022-11 Sensors Amphenol Advanced Sensors

[Nov 9 2022] Made from Amphenol Advanced Sensors, Telaire T6793 is a miniature non-dispersive gold-plated optical component, single channel OEM CO2 sensor module for diffusion style, which has the accuracy and reliability of many large sensors on the market. It also meets the accuracy standard of CA Title 24. Telaire's T6793 has an accuracy rating of ±45 ppm plus 3% readings in the 400 ppm to 2,000 ppm measur ...

2022-11 Power Monolithic Power Systems Inc.

[Nov 8 2022] Monolithic Power System (MPS) MP6527 half bridge motor driver is a 10 channel, half bridge DMOS output driver and integrated success rate mosfet. These motor drivers achieve an output current (IOUT) of up to 0.8A in the input voltage (VIN) range of 5.5V to 40V. The standard serial data interface controls ten half bridges respectively, and each half bridge has various diagnostic functions. These d ...

2022-11 Power Microchip Technology

[Nov 8 2022] Microchip Technology LAN8831 Gigabit Ethernet transceiver and GMII/MII/RGMII are fully integrated three speed (10BASE-T/100BASE-TX/1000BASE-T) Ethernet physical layer transceiver. The equipment is designed to transmit and receive data through standard CAT-5, CAT-5e and CAT-6 unshielded twisted pair (UTP). Microchip LAN8831 Gigabit Ethernet transceiver provides industry standard GMII/MII (Gigabit ...
