Technology Articles

2023-01 Semiconductors Texas Instruments

[Jan 22 2023] Texas Instruments OPAx328 operational amplifier is single-channel and dual-channel precision. Low-voltage CMOS operational amplifier is optimized for low noise and wide bandwidth. OPAx328 has a linear input stage with zero cross distortion, and the common mode rejection ratio (CMRR) reaches 120dB (typical) in the full input range. The input common-mode voltage range of the equipment extends 100mV ...

2023-01 Power Traco Power

[Jan 22 2023] The TRACO Power TEL 15N and TEL 15WIN converters are 15W power converters with a power density of 4.51W/cm(3) in a pi-16 metal case only 0.94 "x 0.54" x 0.40 ". The TEL 15N series has a 2:1 input range, while the TEL 15WIN has a 4:1 input voltage range, and both series are available in radiator housing versions that support extended thermal performance to +70°C. These converters have a high effic ...

2023-01 Semiconductors Texas Instruments

[Jan 22 2023] Texas Instruments BQ756506-Q1 Auto 6S Precision Battery monitor features high precision battery voltage measurement up to 6S battery modules. The device provides these measurements in less than 200 μs, while also supporting shunt resistance current sensing measurements. The integrated front-end filter allows the system to implement simple, low-voltage rated, differential RC filters on the cell in ...

2023-01 Semiconductors STMicroelectronics

[Jan 21 2023] The VIPERGAN65 from stmicroelectronics is a high voltage converter with an advanced PWM controller and 650 V GaN power transistor embedded, designed for single-switch flyback converters. Packaged in a small QFN 5x6, it is the smallest in its class and is capable of managing up to 65w of power. The compact device size combined with the high performance and high switching frequency of GaN power dev ...

2023-01 Semiconductors Texas Instruments

[Jan 21 2023] Texas Instruments TPS92665 LED Matrix Manager enables a fully dynamic adaptive lighting solution by providing a single pixel-level LED control. The device consists of four substrings of four integrated switches in series to bypass a single led. A single substring allows the device to receive a single or multiple current sources. The TPS92665 has an internal oscillator. Internal oscillators can be ...

2023-01 Optoelectronics STMicroelectronics

[Jan 21 2023] STMicroelectronics VIPower M0-9 Intelligent high-side switch meets the needs of intelligent vehicles through the partition architecture, with increasingly advanced functions. The stmicroelectronics VIPower M0-9 device integrates functions such as ADC, PWM engine, priority manager and SPI interface or standard parallel interface. The VIPower M0-9 technology features a 40V grooved vertical mosFETs, ...

2023-01 Semiconductors Analog Devices

[Jan 21 2023] Analog Devices ADRF5141 High power transmit and receive switch ic is a 50 ohm reflecting SPDT switch ic manufactured by silicon process. These switching ics are used for transmit and receive applications and incorporate power limiter on the receive path. The ADRF5141 switch ic operates in the frequency range of 6GHz to 12GHz. These high-power switch ics consume low current of 13μA on a positive 3 ...

2023-01 Semiconductors Laird Technologies

[Jan 21 2023] Laird Connectivity i-FlexPIFA series provides robust performance and operates in the 2.4GHz to 2.48GHz frequency range. These antennas are designed for rapid integration into space-constrained enclosures and offer MHF1 and MHF4 connector options. The outward-facing radiant element design in the antenna, when attached to the inside of the plastic housing, provides more flexibility by providing mor ...

2023-01 Semiconductors STMicroelectronics

[Jan 21 2023] The STMicro LSM6DSV16X is a packaged system (SiP) with a 3-axis digital accelerometer and 3-axis digital gyroscope, with three cores for processing acceleration and angular rate data on three separate channels, with dedicated configuration, processing and filtering. The LSM6DSV16X improves performance by 0.65mA in high performance mode and supports alway on low power features to provide consumers ...

2023-01 Semiconductors Texas Instruments

[Jan 20 2023] The Texas Instruments INA296x Ultra precision current detection amplifier measures the voltage drop of the shunt resistance in a wide model range of -5V to 110V, independent of the supply voltage. High precision current measurements are made from a combination of low bias voltage (Max. ±10 μV) and high DC CMRR(typical 166dB) with small gain error (Max. ±0.01%). The Bidirectional INA296x is design ...

2023-01 Semiconductors Texas Instruments

[Jan 20 2023] Texas Instruments TMUX7219M CMOS 2:1 (SPDT) Precision switch is a precision switch with latched immunity in a single channel, 2:1 (SPDT) configuration. The device can have a single power supply (4.5V to 44V), a dual power supply (±4.5V to ±22V), or an asymmetric power supply (e.g. V(DD) = 12V, V(SS) = -5V). The TMUX7219M supports bidirectional analog and digital signals on the source (Sx) and lea ...

2023-01 Semiconductors Texas Instruments

[Jan 20 2023] The Texas Instruments LM25143/ LM25143-Q1 dual synchronous step-down DC/DC controller is derived from the wide vin range controller family for high current single or double output. The LM25143 features a staggered, stackable, peaking current mode control architecture for easy loop compensation, fast transient response, excellent load and line regulation, and precise current sharing with parallel ...
