Technology Articles

2022-12 Sensors Maxim Integrated

[Dec 16 2022] Maxim Integrated's MAX77827 is a highly efficient buck-boost voltage regulator for 1-battery lithium-ion powered ultra-low static current (6μa) applications. The device supports input voltages from 1.8V to 5.5V and output voltage ranges from 2.3V to 5.3V. buck-boost regulators are available in two different switching current classes (1.8 A and 3.1 A) to optimize the size of external components fo ...

2022-12 Semiconductors ON Semiconductor

[Dec 15 2022] The onsemi NCP1118x mWSaver integrates a peak current mode PWM controller to implement mWSaver technology and a highly robust 800V SJ MOSFET. This integrated design provides a significantly improved performance flyback on the NCP1118x. mWSaver technology reduces the switching frequency and operating current of the controller under light load conditions, thereby avoiding noise problems and even me ...

2022-12 Sensors Bosch Sensortec

[Dec 15 2022] Bosch Sensortec's BMP390L is ideal for industrial applications requiring high performance and low power consumption. Barometric sensors provide high temperature stability across the entire temperature and pressure range, as well as low short - and long-term drift. This makes the sensor very robust and suitable for demanding industrial use cases. It is a compact 10-pin 2.0mm x 2.0mm x 0.75mm LGA p ...

2022-12 Semiconductors Broadcom

[Dec 15 2022] Broadcom AcPL-C740 is a 1-bit, second-order sigma-delta modulator that converts analog input signals into high-speed data streams through current isolation based on optical coupling technology. The ACPL-C740 operates on a 5v power supply with a dynamic range of 86 dB and appropriate digital filters. The ±200 mV(±320 mV at full scale) differential input is ideal for applications that connect direc ...

2022-12 Semiconductors Texas Instruments

[Dec 15 2022] Texas Instruments AMC22C11-Q1 Automotive Class Isolated comparator is an isolated comparator with short response time. The open - drain output and input circuits are separated by isolation grids. The isolation grid is highly resistant to magnetic field interference. It is certified to provide current isolation up to 3kVRMS in compliance with DIN EN IEC 60747-17 (VDE 0884-17) and UL1577 standards. ...

2022-12 Semiconductors Texas Instruments

[Dec 15 2022] Texas Instruments DRV8428 stepper motor driver is for industrial and consumer applications. The device is fully integrated, with two n-channel power MOSFET h-bridge drivers, a micro step indicator and an integrated current sensor. DRV8428 can drive 1A full size output current (depending on PCB design). Texas Instruments DRV8428 adopts an internal current detection architecture, eliminating the ne ...

2022-12 Semiconductors Analog Devices

[Dec 15 2022] Texas Instruments DRV8886 is a stepper motor driver for industrial and consumer terminal device applications. The device fully integrates two n-channel power MOSFET H-bridge drivers, microstep divider, and integrated current sensing. The DRV8886 is capable of driving up to 2 A full-scale or 1.4 A rms output currents (24 V and T(A) = 25°C, depending on the PCB design). DRV8886 uses an internal cur ...

2022-12 Semiconductors Texas Instruments

[Dec 14 2022] The Texas Instruments INA188 is a precision instrument amplifier that uses TI's proprietary automatic zeroing technology. This allows for low bias voltage, near zero bias and gain drift, excellent linearity, and extremely low noise density (12 nV/√Hz), extending to DC. INA188 is optimized to provide common-mode suppression better than 104 dB (G≥10). Superior common-mode and power rejection suppor ...

2022-12 Semiconductors Texas Instruments

[Dec 14 2022] The Texas Instruments DRV10987 device is a three-phase sensorless 180° sinusoidal motor driver with integrated power mosFEts that can deliver up to 2a continuous drive current. The equipment is specifically designed for cost-sensitive, low noise, low number of external parts fan and pump applications. Provides current to the motor at a supply voltage as low as 6.2V. When the supply voltage is hig ...

2022-12 Semiconductors Texas Instruments

[Dec 14 2022] Texas Instruments' CC2564MODx module is a complete Bluetooth BR/EDR and low power HCI solution that reduces design effort, cost and time to market. The CC2564MODx module includes the 7th generation core of TI and provides a universal, product-proven solution compatible with Bluetooth 4.1. These modules are FCC certified, IC and CE certified and no prior RF experience is required to develop these ...

2022-12 Semiconductors Analog Devices

[Dec 14 2022] Analog Devices' ADF5610 allows fractional n or integer n phase-locked loop (PLL) frequency synthesizers to be used with external loop filters and external reference sources. Wideband microwave voltage controlled oscillators (VCO) are designed to allow frequency operation from 7300 MHz to 14600 MHz at a single radio frequency (RF) output. A series of dividers with differential frequency outputs al ...

2022-12 Connectors Alliance Sensors Group

[Dec 14 2022] Alliance Sensors GHS-19 series of linear variable inductance sensors (LVIT) spring position sensors measure in QA laboratories through the dimensions of non-contact equipment design of alliance sensor groups, or position measurement is applied to factory automation systems, automobile and other industrial and commercial application testing, mil/aviation testing. The sensing elements of robot arms ...
