Technology Articles

2022-12 Power Murata

[Dec 4 2022] The Murata SCR410T-K03 gyroscope features a high-performance angular velocity sensor element based on Murata capacitive 3D-MEMS technology. These gyroscopes are Murata's SCC400T series. Signal processing is done in a mixed-signal ASIC that provides angular velocity and acceleration output through a flexible SPI digital interface. SCR410T-K03 series has ±300°/s X axis or X/Z axis angular rate meas ...

2022-12 Semiconductors Texas Instruments

[Dec 4 2022] Texas Instruments TPS563300 3A Synchronous step-down Converter is an easy-to-use, efficient step-down converter with a wide input voltage range of 3.8V to 28V. The device supports output voltages from 0.8V to 22V and continuous output currents up to 3A. The device uses a fixed frequency peak current control mode to achieve excellent line, load regulation and fast transient response. Internal loop ...

2022-12 Sensors Amphenol Advanced Sensors

[Dec 4 2022] Amphenol Communications Solutions ND9 Series ix Industrial Ethernet cable is a reliable micro Ethernet interface that connects RJ45, right Angle and cable components. These cables save up to 75% PCB space compared to standard RJ45 jacks (in accordance with IEC 61076-3-124). The ND9 connector supports IEEE 802.3bt defined PoE++ (up to 100W) and 360° shielding (for excellent EMC suppression). Compa ...

2022-12 Power Diodes Incorporated

[Dec 3 2022] Diodes Incorporated PI2DPX20xx Linear ReDrivers provide transparent channel link training, with ultra-low signal delay, which can achieve good signal integrity and system compatibility. PI2DPX2020 is a high-performance 1.8V linear switching driver product, which supports 20Gbps USB4 Type-C single port or dual port operation, provides flexible working mode, and supports additional protocols, inclu ...

2022-12 Semiconductors Infineon Technologies

[Dec 3 2022] The Infineon TLE4971 XENSIV Magneto-current Sensor is a high-precision miniature coreless magneto-current sensor for both AC and DC measurements, featuring two fast overcurrent detection outputs and an analog interface. Infineon's proven and rugged monolithic Hall technology enables highly linear, accurate current measurements up to 120A at full scale. ± This sensor is equipped with internal self ...

2022-12 Semiconductors Texas Instruments

[Dec 3 2022] The Texas Instruments DS320PR810 eight-channel conversion drive is a low-power, high-performance linear repeater or conversion drive designed to support PCIe 5.0, CXL 2.0, UPI 2.0, and other interfaces at speeds up to 32Gbps. The device also features low AC and DC gain variations, providing consistent balance in high-volume platform deployments. The DS320PR810 receiver uses a continuous time line ...

2022-12 Semiconductors Texas Instruments

[Dec 3 2022] Texas Instruments AMC22C12/AMC22C12-Q1 Isolated window comparator is an isolated window comparator with short response time. The leak-open output is separated from the input circuit by an isolation gate with high anti-magnetic interference capability. The barrier is certified to provide current isolation up to 3kVRMS in compliance with DIN EN IEC 60747-17 (VDE 0884-17) and UL1577 standards. It al ...

2022-12 Semiconductors Microchip Technology

[Dec 3 2022] Microchip Technology AVR32DD and AVR16DD 8-bit microcontrollers are based on AVR cpus (with hardware multiplier, running clock speeds up to 24MHz across the entire supply voltage range from 1.8V to 5.5V). The AVR32DD and AVR16DD MCU are designed to provide real-time control and multi-voltage operation for applications such as industrial control, home appliance products, automotive and Internet of ...

2022-12 Semiconductors Microchip Technology

[Dec 3 2022] Microchip Technology AVR64DD 8-bit microcontrollers are based on AVR cpus (with hardware multiplier, running clock speeds up to 24MHz across the entire supply voltage range from 1.8V to 5.5V). The AVR64DD MCU is designed to provide real-time control and multi-voltage operation for applications such as industrial control, home appliance products, automotive and Internet of Things (IoT). AVR64DD MC ...

2022-12 Power Monolithic Power Systems Inc.

[Dec 2 2022] MPS EVQ4317-R-01A Evaluation board Used to evaluate the running status of MPQ4317. The MPQ4317 synchronous step-down converter provides configurable frequencies that integrate internal high - and low-side power MOSFETs. The MPQ4317 has up to 7A high efficiency output current (IOUT) with current mode control for fast loop response. The MPQ4317 converter supports a wide input voltage (VIN) range of ...

2022-12 Semiconductors Amphenol Advanced Sensors

[Dec 2 2022] Amphenol RF Black plated N-type, SMA, BNC and TNC series connectors are plated with cadmium free, non-reflective zinc-Co alloy coating for enhanced durability in harsh environments. The anti-corrosion coating of this series of connectors withstands 48-hour salt spray environmental testing, making it ideal for use in demanding land, sea and air environments. Black zinc-Co coating is non-reflective ...

2022-12 Power Schurter

[Dec 2 2022] The Schurter MSM wire switch is a mechanical switch with different versions of stroke LA(latching) and MO(instant). These MSM metal line switches have flat plug-in terminals to allow for fast connections. MSM metal line switch has torsion protection for easy operation. These MSM wire switches feature high quality stainless steel or aluminum housing materials and attractive tactile feedback. MSM w ...
