Technology Articles

2022-12 Power Recom Power

[Dec 2 2022] RECOM Power REC150H-UW and REC300H-W half-brick packaged DC/DC converters offer output power up to 150W or 300W, respectively. Both variants feature a wide input range and a tightly regulated, fully protected output voltage option, and both can be fine-tuned within a range of ±10%. The REC300H-W series offers 9VDC to 36VDC input range and 3kVDC/1 min insulation. The REC150H-UW unit has an input r ...

2022-12 Semiconductors Texas Instruments

[Dec 2 2022] Texas Instruments BQ25620/BQ25622 Step-down Battery Charger is a highly integrated 3.5A switch mode battery charge management and system power path management device for single lithium-ion and lithium-polymer batteries. The solution is highly integrated with built-in current detection, loop compensation, input backblocking FET (RBFET, Q1), high-side switch FET (HSFET, Q2), low-side switch FET (LS ...

2022-12 Connectors Kionix Inc.

[Dec 2 2022] Kinetic Technologies KTS1698 VBUS Current sink protection load switches are optimized to protect systems with USB Type-C PD ports and barrel connectors. The equipment is suitable for applications sinking to 100W at 20V and must withstand voltages up to 29V on the VBUS. The KTS1698 features soft start, overvoltage protection, reverse current blocking, overcurrent protection, short circuit protecti ...

2022-12 Optoelectronics Keystone Electronics

[Dec 1 2022] Keysight Technologies E36150 Automatic Ranging Desktop DC Power Supply is available in two models with 800W power workbench solutions that can be supplied up to 60V or 80A. These automatic ranging benchtop power supplies show peak power handling up to 3 times the maximum power rating. E36150 series automatic ranging power supply is safe, clean, reliable, low output ripple and noise, line/load reg ...

2022-12 Power Monolithic Power Systems Inc.

[Dec 1 2022] Monolithic Power System (MPS) MP2651 Buck-Boost Charger ic is designed for battery packs of one to four cells in series. The MP2651 offers a wide input voltage (VIN) range of 4V to 22V to charge the battery. The device's step-boost topology authorized battery voltage is higher or lower than VIN. The MPS MP2651 Buck-Boost Charger ic operates in charge mode when input is present. The device can mea ...

2022-12 Semiconductors STMicroelectronics

[Dec 1 2022] The NUCLEO-NFC08A1 NFC Card reader expansion board provides a demonstration and development platform for the ST25R3916B NFC card reader. The ST25R3916B is a high-performance NFC (Near Field communication) general-purpose device that supports NFC initiators, NFC targets, NFC card readers, and NFC card emulation modes (if applicable). Fully compliant with EMVCo 3.1a analog and digital standards, th ...

2022-12 Power Texas Instruments

[Dec 1 2022] Texas Instruments AMC1400-Q1 Precision Isolation amplifier is a precision isolation amplifier that separates output and input circuits through an isolation gate. The barrier is highly resistant to magnetic field interference. The isolator is certified to provide enhanced current isolation up to 7.5kVRMS in compliance with DIN EN IEC 60747-17 (VDE 0884-17) and UL1577 standards. It supports operati ...

2022-12 Power Texas Instruments

[Dec 1 2022] Texas Instruments TLV61070A 2A Boost converter is a synchronous boost converter with an ultra-low input voltage of 0.5V. The device provides a power solution for portable devices and smart devices powered by a variety of batteries and supercapacitors. The TLV61070A has A 2.5-A valley switching current limit typical throughout the temperature range. The TLV61070A has a wide input voltage range of ...

2022-12 Semiconductors Texas Instruments

[Dec 1 2022] The TPS55289 has input voltage capability up to 30v. Through the I2C interface, the output voltage of the TPS55289 is programmable, from 0.8V to 22V, with a step of 10 mv. When operating in boost mode, the device can provide 60w from 12v input voltage. It is capable of delivering 45 W from 9 v input voltage. TPS55289 adopts average current mode control scheme. Switching frequencies are programmab ...

2022-11 Power Texas Instruments

[Nov 30 2022] Texas Instruments UCC21737-Q1 Single-channel gate driver is a current isolated gate driver designed for use with SiC MOSFETs and IGBTs, operating at voltages up to 2121V DC, offering advanced protection features, best-in-class dynamic performance, and robustness. The device has up to ±10A peak pull current and perfusion current. The input side is isolated from the output side by SiO2 capacitive i ...

2022-11 Semiconductors Analog Devices

[Nov 30 2022] Analog Devices DC2652A-A Demo Board is an 8-phase dual-output, high-efficiency, high-density synchronous step-down converter with input voltage range of 7V to 14V for the demonstration of the LTC3888. Independent output provides up to 120A maximum load current (at 1V). The LTC3888 is a PMBus compatible dual-loop 8-phase step-down DC/DC controller with digital power system management capabilities ...

2022-11 Semiconductors Analog Devices

[Nov 30 2022] Analog Devices AD-SYNCHRONA14-EBZ Multi-channel System Clock device is a standalone device designed to evaluate and prototype applications that require high precision frequency and phase control source clocks. AD-SYNCHRONA14-EBZ is based on AD9545 and HMC7044 to simplify clock allocation and multi-channel synchronization in complex systems. The device is intended to be used by trained professiona ...
