Technology Articles

2022-11 Power ABLIC

[Nov 30 2022] ABLIC S-82M1A, S-82N1A, and S-82N1B battery protection ics provide longer battery life and increased safety, and have ultra-low 990nA(maximum) current consumption during operation. The device is designed for single lithium-ion and lithium-polymer rechargeable batteries with overcharge detection voltage accuracy up to ±15mV. The ABLIC S-82M1A Battery protection IC uses an external current detectio ...

2022-11 Power Phoenix Contact

[Nov 30 2022] Phoenix Contact TCP thermal element circuit breakers provide optimal overload protection for distribution systems. The integrated switch function ensures immediate restart when the circuit breaker trips. Unlike fuses, circuit breakers do not need to be replaced. The larger the overload, the faster the thermal element circuit breaker trip. Phoenix Contact TCP Thermal element Circuit breakers conta ...

2022-11 Sensors Sensirion AG

[Nov 29 2022] The Sensirion SHT40I-HD1B analog humidity sensor has been developed specifically for demanding industrial applications, such as refrigerators, air conditioners, and any other applications where the system is noisy and where digital solutions are not available. The SHT40I-HD1B features a 5V supply voltage, rugged housing, and enhanced ESD protection to meet the requirements of harsh operating envi ...

2022-11 Power Diodes Incorporated

[Nov 29 2022] Diodes Inc. AP43776 USB Type-C protocol decoder is a highly integrated dual-channel USB Type-C, PD3.1/PPS/QC5 protocol decoder. It is PPS and QC5 protocol certified by USB Type-C Power Supply Specification Revision 3.1V1.1. The device supports a full range of PPS APdos (enhanced Power data Objects) from 3.3V to 21V (voltage resolution at 20mV per step) and up to 6A current (current resolution at ...

2022-11 Power Diodes Incorporated

[Nov 29 2022] Diodes Incorporated AP25810LQ USB Type-C DFP controller and power switch are designed to monitor USB Type-C Configuration channel (CC) wiring to determine when to connect a USB device. When connected to an upstream port (UFP) component, the AP25810LQ supplies power to the VBUS. It also delivers optional VBUS current source functionality to the UFP via a straight-through CC line. If an electronica ...

2022-11 Semiconductors Analog Devices

[Nov 29 2022] Analog Devices LT8355-1 Dual-channel LED Controller is a dual-channel constant frequency, constant current/constant voltage (CC/CV) step-up power level controller designed to drive two strings of high-current leds. With a fixed-frequency, current-mode architecture, the LT8355-1 operates stably over a wide range of power supplies and output voltages. Voltage feedback pins can be used as inputs for ...

2022-11 Power Alliance Memory, Inc.

[Nov 29 2022] Alliance Memory AS25F serial NOR flash combines fast read performance of up to 133MHz with fast programming and erase times. The device is in an 8-pin SOP wide-body (209mils) and 8L WSON (6.0mm x 5.0mm) package and operates with a single 1.6V to 3.6V power supply in the industrial temperature range of -40°C to +85°C. The solution supports single, dual, and quad SPI modes and provides reliable lon ...

2022-11 Semiconductors TDK-Lambda

[Nov 29 2022] The TDK-Lambda PYH200 200W single-output DC-DC converter is a 200W DC-DC converter mounted on a board, with a solid half-brick housing with silicone potty seal. The TDK-Lambda PYH200 DC-DC converter provides voltage stabilizer and current isolation output voltage. The series has a 14V to 160V (12:1) input voltage range and 3000VAC input/output (I/O) isolation strength. These DC-DC converters have ...

2022-11 Semiconductors ON Semiconductor

[Nov 28 2022] The onsemi NCN26010XMNEVB Evaluation board is the demonstration and development platform for the NCN26010 Industrial Ethernet transceiver. NCN26010 A 10Mb/s IEEE 802.3CG-compliant device that includes a media access controller (MAC), a PLCA coordination sub-layer (RS), and a 10BASE-T1S PHY designed for industrial multipoint Ethernet. The NCN26010 provides all the physical layer functions required ...

2022-11 Semiconductors Texas Instruments

[Nov 28 2022] Texas Instruments TPS22963/64 Load switch is a small ultra low RON load switch with controlled on-on function. The device uses a low RDSON N channel MOSFET and can operate in the input voltage range of 1V to 5.5V. It can also switch electric currents up to 3A. The integrated charge pump can bias the NMOS switch to obtain a low switching on-resistance. The switch is controlled by an ON/off input ( ...

2022-11 Semiconductors Texas Instruments

[Nov 28 2022] Texas Instruments TPS629203/TPS629203-Q1 Low IQ step-down converter is an efficient, small, flexible synchronous step-down DC-DC converter that is easy to use. The wide input voltage range of 3V to 17V supports a variety of systems powered by 12V, 5V, or 3.3V power rails, and single or multiple lithium-ion batteries. The TPS629203/TPS629203-Q1 can be configured to operate at either 2.5MHz or 1MHz ...

2022-11 Semiconductors Texas Instruments

[Nov 28 2022] Texas Instruments HDC302x/ HDC302X-Q1 Digital humidity sensor is an integrated capacitive relative humidity (RH) and temperature sensor. It comes in a compact 2.5mm x 2.5mm package that provides high precision measurements over a wide power range (1.62V to 5.5V) with ultra-low power consumption. The temperature and humidity sensors are 100% tested and adjusted in an NIST-traceable production envi ...
