Technology Articles

2022-12 Power Monolithic Power Systems Inc.

[Dec 6 2022] Monolithic Power System (MPS) MP5981 Hot Swap Controller Solution IC is a monolithic integrated controller and switch that contains high-side MosFETs and other circuits. The MP5981 comes in a LGA-32 (5mmx5mm) package. These circuits enable it to work independently or be controlled by a hot-swap controller. The MP5981 drives up to 50A continuous current per unit at room temperature. When there is ...

2022-12 Semiconductors Infineon Technologies

[Dec 6 2022] Infineon Technologies MA2304xN MERUS™ Multistage Switched audio amplifier is a 2W × 37W audio amplifier that uses MERUS multistage switched amplifier technology to achieve excellent power efficiency at both low and high output power. The device's multistage switching reduces EMC requirements and provides inductorless applications at a lower cost. The MA2304xN features a high-order internal feedba ...

2022-12 Power Maxim Integrated

[Dec 6 2022] Maxim Integrated MAX20079 36V step-down Converter is a small automotive grade synchronous step-down converter with integrated high side and low side switches. The device provides up to 3.5A current with input voltages ranging from +3V to +36V and static current of only 3.5μA when unloaded. MAX20079 supports ±2% accurate output voltage in the normal operating input range from +6V to +18V. The conv ...

2022-12 Semiconductors Microchip Technology

[Dec 5 2022] Microchip Technology LAN8830 Gigabit Ethernet transceiver (with RGMII function) is an integrated three-speed (10Base-T/100Base-TX/1000Base-T) Ethernet physical layer transceiver. Designed to transmit and receive data over standard CAT-5, CAT-5e, and CAT6 unshielded twisted pair (UTP) cables. The LAN8830 features RGMII (simplified Gigabit media independent interface) for connecting Ethernet switch ...

2022-12 Semiconductors NXP

[Dec 5 2022] The NAFE11388 is a highly configurable industrial-grade multi-channel general-purpose input analog front end (AFE) designed to meet high precision measurement requirements. The device integrates a low-leakage, high-voltage (HV) fast multiplexer, a low bias and low drift programmable gain amplifier (PGA) and buffer, a high data rate 24-bit Delta-Sigma analog-to-digital converter (ADC), and a low d ...

2022-12 Semiconductors Diodes Incorporated

[Dec 5 2022] Diodes Incorporated PI2DPT1021 10Gbps two-way reweight timer is a bit-level reweight timer with receiver Adaptive-Ctle and transmitter 3-tap equalize that compensates channel losses of up to -23dB for 5GHz signal transmission. It supports USB Type-C™ DP running in alternate mode with the DP 1.4 and USB 3.2 standards. The operation configuration can be programmed through the I2C interface to selec ...

2022-12 Semiconductors Texas Instruments

[Dec 5 2022] Texas Instruments AMC23C12/AMC23C12-Q1 Isolated window comparator has a short response time. The leak-open output is separated from the input circuit by an isolation gate with high anti-magnetic interference capability. The isolator is certified to provide enhanced current isolation up to 5kVRMS in compliance with VDE 0884-17 and UL1577 standards. It also supports operating voltages up to 1kVPK. ...

2022-12 Semiconductors Texas Instruments

[Dec 5 2022] The INA241x is an ultra-precision bi-directional current sensing amplifier that measures the voltage drop of the shunt resistance in a wide common-model range from -5v to 110v, independent of the supply voltage. High precision current measurement is achieved through a combination of low bias voltage (Max. ±10 μV), small gain error (Max. ±0.01%), and high DC CMRR(typical 166 dB). The INA241x is de ...

2022-12 Power Renesas Electronics America

[Dec 5 2022] Renesas Electronics RTKA271082DE0000BU Evaluation Board is configured to evaluate the operation of PMIC for RAA271082 vehicle. The RAA271082 features three synchronous step-down regulators and one low-voltage differential linear regulator. The Renesas RTKA271082DE0000BU evaluation board is designed for point-of load automotive applications, including camera systems, with input power voltage range ...

2022-12 Sensors Eaton - Bussmann Electrical Division

[Dec 4 2022] The Eaton ACE2V3225 common-mode Chip inductor is an automotive class chip inductor that complies with the AEC-Q200 standard and meets the OPEN Alliance 2.0 standard. These chip inductors provide excellent filtering and low parasitic capacitance to minimize noise intrusion into the data lines of CAN and Ethernet vehicle connection modules. ACE2V3225 chip inductors have a common-mode inductance ran ...

2022-12 Sensors Qorvo US Inc.

[Dec 4 2022] The Qorvo QPQ1065EVB01 Evaluation board is a demonstration and development platform for the QPQ1065 AltNav bandpass SAW filter. QPQ1065 is a compact high performance surface acoustic wave (SAW) filter optimized for GPS applications. The QPQ1065 is designed to suppress unwanted signals and also has excellent power handling capabilities, making it suitable for use in low power transmitters. No matc ...

2022-12 Power UDOO

[Dec 4 2022] The u-blox NOL-W2 multi-radio module is a standalone module that integrates a 32-bit dual-core microcontroller unit (MCU) and a radio for wireless communication. The radio supports Wi-Fi 802.11b/g/n and BLUETOOTH® Low Power (LE) v5.0 in the 2.4GHz ISM band. Embedded AWS IoT ExpressLink compatible software includes a security certificate pre-embedded in the module. This allows the module to provid ...
