Technology Articles

2022-10 Power Cornell Dubilier Electronics (CDE)

[Oct 19 2022] The CHW1010 of CoreHW is a monolithic phase matched SP16T antenna switch array, and the CHW1020 is a monolithic phase matched SP8T differential antenna switch array. Both are applicable to Bluetooth AoA and AoD DF devices. The low phase mismatch between switch paths can minimize the residual error of beam direction angle calculation, thus improving the prediction positioning accuracy. A single CH ...

2022-10 Power Grayhill Inc.

[Oct 19 2022] GroupGets PureThermal OpenMV is a high-end hybrid color and thermal imager for professional applications. The board's sensors include a 5 MP OV5640 camera module, a FLIR Lepton socket that can support any FLIR Lepton, and a VL53L0X laser rangefinder to help draw thermal images on top of color images using the correct offset/zoom. Live video can be displayed via an onboard 4.3" 800x480 IPS TFT cap ...

2022-10 Semiconductors STMicroelectronics

[Oct 19 2022] STMicroelectronics' STEVAL-ASTRA1B development suite and reference design simplify prototype development, testing and evaluation of advanced asset tracking applications such as livestock monitoring, fleet management and logistics. The kit consists of four boards (not sold separately) : STEVAL-ATRA1 (motherboard), STEVAL-ASTRA1SB (onboard system), STEVAL-ATRA1BC (expansion board), and STEVAL-ASTRA ...

2022-10 Power Qualtek

[Oct 19 2022] Qualtek's QKRC-10-05 freestanding socket system includes a power supply unit that converts AC input to 5 V 2 ADC output power. To install, simply clip the socket into the panel or system and connect the supplied 24 inch lead to the 120 VAC input. QKRC-10-05's patent pending compact design allows systems with Qualtek convenience outlets to add active USB-C ports without changing the user's current ...

2022-10 Power Panasonic

[Oct 19 2022] Panasonic extends its TPE line of POSCAP conductive polymer tantalum solid capacitors. The POSCAP TPE series offers more than 100 unique part numbers and is ideal for a variety of applications. POSCAP capacitors use sintered tantalum as the anode system and a highly conductive polymer made from Panasonic's unique method as the cathode system. This allows POSCAP capacitors to be thin and small, wh ...

2022-10 Semiconductors Wurth Electronics

[Oct 19 2022] Wurth Electronics REDEXPERT is an accurate simulation platform based on measurements to help users select the right device. Now, with the embedded EMI filter design module, the platform has easy-to-use anti-EMI filter development capabilities. This capability will continue to be extended, and the current first version allows the design of discrete element low-pass filters for conducting different ...

2022-10 Power STMicroelectronics

[Oct 18 2022] The IPS1025H, IPS1025H-32 and IPS1025HF of STMicroelectronics are monolithic architectures with M0T5 VIPower technology and are packaged with PowerSSO-24. These ICs are single high-voltage side switching devices, which can drive capacitive, resistive or inductive loads (high-voltage side switches) grounded on one side. The working voltage is recommended to be in the range of 8 V to 60 V, but the ...

2022-10 Power Allegro MicroSystems, LLC

[Oct 18 2022] Allegro's A31010 linear Hall effect sensor IC provides a voltage output proportional to the applied magnetic field. These unipolar Hall effect sensors provide optimum performance for frontal push-pull applications. These unipolar sensors are only sensitive to a single specific magnetic pole; Therefore, when measuring the range from 0 G to full scale, the full scale of the output is used. The user ...

2022-10 Power Allegro MicroSystems, LLC

[Oct 18 2022] Allegro's A89506 full bridge grid driver is designed for pulse width modulation (PWM) control of DC motors. They can operate at 50 V and provide gate drive for all N-channel external MOSFET bridges to reduce EMI. The fault output can inform the microprocessor of bridge short circuit or overcurrent events. The input terminal controls the speed and direction of the DC motor through externally appli ...

2022-10 Power Apex Microtechnology

[Oct 18 2022] Abracon's onboard stamped metal antenna supports planar inverted F antenna (PIFA) technology. The use of stamping metal makes the implementation cost of antenna technology very low. These antennas are supplied in reels for electronic assembly. OnBoard SMD antenna is a safe choice for robust connection in wireless applications. OnBoard stamping metal antenna can be placed under the components and ...

2022-10 Power KEMET

[Oct 18 2022] KEMET's CHT series high-temperature 260 ° C surface mount multilayer ceramic capacitors (MLCC) are composed of a robust proprietary C0G/NP0 base metal electrode (BME) dielectric system, which can provide industry-leading performance at extreme temperatures. These devices are designed for applications in harsh environmental conditions, such as downhole oil exploration, industrial high-temperature ...

2022-10 Semiconductors Rohm Semiconductor

[Oct 18 2022] ROHM's LTR100L series thick film shunt resistors are optimized for industrial and consumer applications. Shunt resistors are often used to detect current in battery protection and motor drive circuits, requiring higher accuracy to improve reliability and ensure efficient operation. In recent years, industrial and consumer fields have begun to pay attention to energy conservation and use motor inv ...
