Technology Articles

2023-03 Power Murata

[Mar 25 2023] The Murata 2XS Wi-Fi + Bluetooth module is a small high-performance module based on the NXP 88W9098 chipset. The 88W9098 chipset supports Wi-Fi 802.11a/b/g/n/ac/ax 2x2 MIMO + Bluetooth 5.3 BR/EDR/LE 2MPHY. The Murata 2XS Wi-Fi + Bluetooth modules are 2.5GHz and 5GHz modules with PHY data rates up to 1200Mbps on Wi-Fi and 3Mbps on Bluetooth. The 2XS includes an embedded reference clock with PCIe/S ...

2023-03 Semiconductors NXP

[Mar 25 2023] NXP Semiconductors GoldBox 3 Vehicle Network development platform is designed for vehicle service-oriented gateways (SOGs), domain control applications, high-performance processing, and safety and security applications. The development platform provides high-performance computing power, real-time network performance, multi-gigabit packet acceleration, security, and rich input/output (I/O). These ...

2023-03 Semiconductors Texas Instruments

[Mar 25 2023] The Texas Instruments DS90LVRA2EVM Evaluation Module is designed to evaluate the performance and functionality of the DS90LVRA2 dual-way CMOS differential line receiver. The evaluation module can quickly evaluate the output waveform characteristics and signal integrity supported by the DS90LVRA2 receiver. The DS90LVRA2 receiver is designed for applications requiring high input common model circum ...

2023-03 Semiconductors STMicroelectronics

[Mar 25 2023] The stmicroelectronics TSB621 Low Power op-amp is a general-purpose dual op-amp with an extended operating supply voltage range (2.7V to 36V) and rail-to-rail output. The TSB621 has an excellent speed/power ratio with a gain bandwidth of 1.7MHz and power consumption of less than 375μA per operator when powered at 36V. Operating temperatures range from -40°C to +125°C, the SOT23-5 packaged TSB621 ...

2023-03 Power Littelfuse

[Mar 25 2023] Littelfuse AQ31xE-01ETG two-way TV diodes offer typical 0.3pF capacitance, 1nA leakage current, and 18V or 28V reverse stand-off voltage ratings. These diodes offer ultra-low capacitance, a two-way design, and a high level of protection for electrical equipment that is vulnerable to destructive electrostatic discharge (ESD). Low capacitance ratings help ensure excellent signal integrity even on t ...

2023-03 Power Taoglas

[Mar 24 2023] Taoglas Universe personal Computer. The Low-Profile SMD antenna is an active cellular and GNSS antenna designed for Internet of Things devices with small ground planes. PCS.60. The antenna combines aperture tuning and active switching technologies to provide broadband coverage for GNSS and most 5G/4G LTE cellular bands, including the challenging 600MHz to 700MHz bands. The antenna is easy to inte ...

2023-03 Optoelectronics Taoglas

[Mar 24 2023] The Taoglas Bolt A.85 Permanently Mounted antenna is a high-gain GNSS L1/L5 (GPS/GLONASS/Galileo/Beidou) antenna with a low profile, damage resistant design. The antenna has high out-of-band suppression and handles high-power bursts from nearby transmitters, allowing continuous operation. a. The 85 L1/L5 GNSS permanently mounted antenna uses an efficient patch antenna that optimizes performance w ...

2023-03 Power TE Connectivity

[Mar 24 2023] The AMP Micro CT connector is designed to provide an economical line routing solution for power or signal needs. These connectors provide impressive performance in their harness-making capabilities. AMP MicroCT connectors feature IDC terminals, discrete wire interconnects and AWG 26 to 28 cable sizes. These CT connectors offer a wide range of configurations, with circuits ranging from 2-25 single ...

2023-03 Semiconductors NXP

[Mar 24 2023] The NXP Semiconductor S32G Vehicle Network Processing Evaluation Board 3 is designed for vehicle service-oriented gateways (SOGs), domain control applications, high-performance processing, and safety and security applications. The evaluation board provides a combination of automotive and enterprise networking technologies that provide multiple interfaces to the vehicle network. The S32G eval boar ...

2023-03 Power Qorvo US Inc.

[Mar 24 2023] The Qorvo QPF4617 Wi-Fi 6E Nonlinear front-end module is designed for Wi-Fi 6E (802.11ax) systems. The Qorvo QPF4617 is designed to be used in conjunction with DPD correction. The device features a smaller contour size and integrated matching that minimizes application layout area. Performance is focused on optimizing the PA efficiency of the 5V supply voltage, minimizing power consumption. This ...

2023-03 Power ECS

[Mar 23 2023] ECS ECS-TXO-TX20CSMV4 MultiVolt Temperature Compensated Crystal Oscillator (TCXO) provides 1.7V to 3.6V MultiVolt capability and stabilizes critical applications using analog compensation. These shear sine wave SMD TCXOs are compatible with 1.8V, 2.5V, or 3.3V power supplies and offer frequency ranges from 10MHz to 52MHz, 10KΩ/10pF output loads, ±1ppm frequency tolerance, and ±0.5ppm or ±1.5ppm f ...

2023-03 Semiconductors Microchip Technology

[Mar 23 2023] Microchip Technology AVR64EA48 Curiosity Nano Evaluation Kit (EV66E56A) is a hardware platform for evaluating AVR®EA family microcontrollers. The board is mounted with AVR64EA48 microcontroller. The board is supported by the MPLAB®X IDE and Microchip Studio for easy access to AVR64EA48's features to explore how the device can be integrated into custom designs. The Huggies Nano series evaluation B ...
