Technology Articles

2023-03 Semiconductors STMicroelectronics

[Mar 18 2023] The STMicroelectronics SM50TxAY 5000W Transient Voltage Suppressor (TVS) is packaged in SMC and is designed to protect sensitive automotive circuits from surges as defined in ISO 7637-2. These voltage suppressors also protect sensitive automotive circuits from electrostatic discharge and meet ISO 10605 standards. The SM50TxAY series transient Voltage suppressors are suitable for use in electronic ...

2023-03 Optoelectronics Amphenol ICC (FCI)

[Mar 18 2023] Ampherol Commercial Ve-NET Automatic multi-gigabit connector system can transmit 1000Mb/s to 10Gb/s based on 1000BASE-T1, 10GBASE-T1, and 50GBASE-CR. The connector system uses shielded twisted pair/shielded parallel cable to transmit data. The entire system was developed according to USCAR-2, LV214, and Ethernet specifications. The Ve-NET connector system makes sound when fitting, avoiding mismat ...

2023-03 Sensors Omron Electronics Inc-EMC Div

[Mar 18 2023] Omron G2RV-ST and G3RV-ST Thin I/O relays are mounted at a high density and have an ultra-thin body with a width of 6.2mm to save application space. These user-friendly relays use Push-In Plus technology with low insertion forces that reduce connection time. These relays are compatible with 14AWG/2.5mm2 wiring, and the larger hole and Angle structure improves wiring efficiency. Improved LED visib ...

2023-03 Power Texas Instruments

[Mar 18 2023] Texas Instruments TLIN1431x-Q1 Automotive LIN SBC is a Local Internet (LIN) system-based chip (SBC) that integrates watchdog, high-side switch, limping home functionality, and highly configurable WAKE input pins. The TLIN1431x-Q1 self-determines the control method, pin, or serial peripheral interface (SPI) at power-on. By default, the watchdog is a window watchdog suitable for both control method ...

2023-03 Power Texas Instruments

[Mar 17 2023] The REG102 is a low noise, low difference linear voltage regulator series with low grounded pin current. Available in sot235-5, SOT223-5, and SO-8 packages. The new DMOS topology features significant improvements over previous designs, including a low voltage drop (only 150mV at full load) and better transient performance. In addition, no output capacitance is required for stability, unlike tradi ...

2023-03 Power Diodes Incorporated

[Mar 17 2023] The RT9193 is designed for portable RF and wireless applications where performance and space requirements are critical. The performance of the RT9193 is optimized for battery powered systems to provide ultra-low noise and low static current. Noise bypass pins can be used to further reduce output noise. The voltage regulator grounding current increases only slightly in dropout, further extending b ...

2023-03 Semiconductors Diodes Incorporated

[Mar 17 2023] Diotec Semiconductor Sx rectifier diodes feature high current ratings, high forward surge current, and RoHS, REACH, and conflict minerals. These diodes support repetitive peak reverse voltages up to 2000V and are AEC-Q101-qualified and UL 94V-0 housing materials. Typical applications include 50Hz/60Hz mains rectifier, power supply, polarity protection, and commercial/industrial grade. Features ● ...

2023-03 Power Analog Devices

[Mar 17 2023] The LTM4628 is a complete dual 8A output switch mode DC/DC power supply that can be easily configured to provide a single 2-phase 16A output. Included in the package are switching controllers, power FETs, inductors and all supporting components. From an input voltage range of 4.5V to 26.5V, the LTM4628 supports two outputs, each in a range of 0.6V to 5.5V, set by a single external resistor. Its h ...

2023-03 Semiconductors ON Semiconductor

[Mar 17 2023] NCP3101C is an efficient 6 a DC-DC step-down converter designed to operate from 5v to 12v power supplies. The device is capable of producing an output voltage as low as 0.8V. The NCP3101C has a continuous output of 6a via an internally set 275 kHz oscillator driven MOSFET switch. The 40-pin device provides the optimal level of integration to reduce the size and cost of the power supply. The NCP31 ...

2023-03 Power Wurth Electronics

[Mar 16 2023] The WurthuElektronik WR-SPASM12 Circular connector is pluggable and lockable, providing a waterproof and dust-proof connection without loss of connection or signal. These connectors feature A-coded, screw-locking systems, 4, 5, and 8 polarity, current ratings up to 5A, and voltage ratings up to 250V. WR-ATHM 12 Circular connectors have IP67 or IP68 protection rating and are UL 2238 certified (pan ...

2023-03 Power Texas Instruments

[Mar 16 2023] Texas Instruments TPSM82913 Synchronous step-down Converter module is a low noise, low ripple step-down module with integrated ferrite bead filter compensation. The module is a fixed frequency current mode converter module with filtering internal reference, which can achieve low noise output similar to low noise LDO. TPSM82913 module adopts 2.2MHz or 1MHz switching frequency to realize low output ...

2023-03 Semiconductors Linx Technologies Inc.

[Mar 16 2023] Linx Technologies surface-mount SWF and SWD RF switch connectors are designed for diagnostic measurements between printed circuit board components. These switch connectors operate at frequencies ranging from 0Hz to 6GHz and provide high isolation between ports to improve data accuracy. SWF and SWD RF switch connectors are designed for reflow soldering directly onto printed circuit boards for high ...
