Technology Articles

2022-11 Power Monolithic Power Systems Inc.

[Nov 24 2022] Monolithic Power Supply System (MPS) MPQ7235 Automotive infrared LED driver provides a high frequency, synchronous, rectifier, step-down, switching mode LED device with integrated power mosfet. The MPQ7235 is AEC-Q100 certified and comes in a space-saving QFN-13 (2.5mm x 3mm) package that requires a minimum number of standard external components. The MPQ7235 provides 1.5A continuous output curren ...

2022-11 Semiconductors Texas Instruments

[Nov 23 2022] Texas Instruments DRV8300U Three-phase Gate drivers feature three half-bridge gate drivers with a voltage of 100V, each capable of driving both a high - and low-side n-channel power MOSFET. The DRV8300UD uses an integrated bootstrap diode and an external capacitor to generate the correct gate drive voltage for a high-side MOSFET. GVDD is used to generate a gate drive voltage for a low-side MOSFET ...

2022-11 Semiconductors Texas Instruments

[Nov 23 2022] Texas Instruments LMK5B33216 Network Synchronizer and jitter eliminator are designed to meet the rigorous requirements of Ethernet-based networking applications with timing accuracy. 5ns (class D). The network synchronizer integrates three DPLLS to provide interruption-free switching. It also has jitter attenuation, programmable loop bandwidth, and no external loop filter. This feature maximizes ...

2022-11 Semiconductors Texas Instruments

[Nov 23 2022] Texas Instruments ESD341 TVS ESD Protection diode is a TVS ESD protection diode for HDMI 1.4 circuit protection. The ESD341 has the highest ESD impact dissipation rating (level 4) specified in IEC61000-4-2 international standard. The device's IO capacitance is 0.66pF (typical value), enabling high-speed interface protection up to 3.4Gbps, including support for protocols such as HDMI 1.4b. Low dyn ...

2022-11 Semiconductors Texas Instruments

[Nov 23 2022] Texas Instruments TPS22811x Load switches are a highly integrated set of power distribution solutions in a small package. The device supports the use of a minimum number of external components to control and monitor the power rail. The output conversion rate and surge current can be adjusted using an external capacitor. If the input exceeds the adjustable overvoltage threshold, the load is protec ...

2022-11 Semiconductors Dialog Semiconductor GmbH

[Nov 23 2022] Dialog Semiconductor SLG47115V-EVB Evaluation Board is the demonstration and development platform for the SLG47115V HVPAK mixed Signal Matrix. The SLG47115V combines mixed-signal logic and high-voltage H-bridge functionality in a tiny 2mm x 3mm QFN package. Disposable Programmable (OTP) non-volatile memory (NVM) stores user-defined solutions in the form of interconnects of internal logic, I/O pin ...

2022-11 Semiconductors Renesas Electronics America

[Nov 23 2022] Renesas Electronics RZ/Five Evaluation Board suite provides a complete demonstration and development platform for RZ/ FIVE-RISC-V microprocessors. The RZ/Five MPU features a RISC-V CPU core (AX45MP single-core) of 1.0GHz and a 16-bit DDR3L/DDR4 interface. The device also includes a variety of interfaces, such as Gigabit Ethernet, CAN, and USB 2.0, making it ideal for entry level social infrastruc ...

2022-11 Semiconductors ON Semiconductor

[Nov 22 2022] The onsemi NCN5140BSCGEVB and NCN5140TSCGEVB evaluation boards are the demonstration and development platforms for the NCN5140S KNX System-level Package (SiP). The NCN5140S integrates the KNX transceiver and Arm® Cortex®-M0+ microcontroller along with the necessary passive components in one device. The rest of the components have high integration and low height, so it can be designed for ultra-th ...

2022-11 Semiconductors Texas Instruments

[Nov 22 2022] Texas Instruments AMC22C11/AMC22C11-Q1 Isolated comparator is an isolated comparator with short response time. The open - drain output and input circuits are separated by an isolation gate. The barrier is highly resistant to magnetic field interference. It is certified to provide current isolation up to 3kVRMS in compliance with DIN EN IEC 60747-17 (VDE 0884-17) and UL1577 standards. It supports ...

2022-11 Semiconductors STMicroelectronics

[Nov 22 2022] The STMicroelectronics STEVAL-L3751V12 evaluation board has a wide input voltage range of 6V to 75V, with an extremely high voltage conversion ratio across the switching frequency range. The board provides a 5V stabilized voltage output at a switching frequency of 230kHz. The output voltage on the STEVAL-L3751V12 board is quickly set to 12V via a jumper connector. Select different voltage outputs ...

2022-11 Semiconductors ON Semiconductor

[Nov 22 2022] The onsemi NCN26010XMNEVK Industrial Ethernet Evaluation Kit includes everything you need to demonstrate the NCN26010 Industrial Ethernet transceiver using a Raspberry Pi single-board computer (not included). NCN26010 A 10Mb/s IEEE 802.3CG-compliant device that includes a media access controller (MAC), a PLCA coordination sub-layer (RS), and a 10BASE-T1S PHY designed for industrial multipoint Eth ...

2022-11 Semiconductors Analog Devices

[Nov 22 2022] Analog Devices LTM4686B Demo Board (DC3089A) is an evaluation platform for the LTM4686B single 28A μModule regulator. The LTM4686B has a digital power management system that communicates via PMBus. This function is an open standard digital interface protocol based on I2C. The device is also remotely configurable. The LTM4686B integrates a high-precision mixed-signal circuit, EEPROM, power MOSFET, ...
