Technology Articles

2022-12 Semiconductors Analog Devices

[Dec 23 2022] The LTC4376 is a 7 a ideal diode with reverse input protection. The device uses an internal 15 mm n-channel MOSFET in place of Schottky diodes when diodes or diodes and high current diodes are applied. LTC4376 reduces power consumption, heat dissipation, and PC board area. The LTC4376 controls forward voltage drop through the internal MOSFEts to ensure smooth current transmission without oscillat ...

2022-12 Semiconductors Apex Microtechnology

[Dec 23 2022] Apex Microtechnology's MP106 is a power amplifier that features a voltage swing up to -48 V, short-term output current over 30 a, drive capacity over 500 nF, and internal power dissipation of 130 W. The MP106 is designed to drive dynamic capacitor-loaded piezoelectric devices such as those used in inkjet printer nozzles. Using Apex's proprietary technology, the MP106 packages discrete semiconduct ...

2022-12 Power Monolithic Power Systems Inc.

[Dec 23 2022] Monolithic Power Systems' MPQ86xx family is fully integrated high frequency, synchronous step-down converters. These converters offer a very compact solution that achieves up to 12 a output current with good load and line regulation over a wide input power range. They operate efficiently over a wide output current load range and use internally compensated normally open time (COT) control to provi ...

2022-12 Optoelectronics KOA Speer Electronics

[Dec 23 2022] KOA Speer Electronics offers a wide range of sheet metal resistors and jumpers to suit a variety of customer needs. TLR series comes in several sizes :TLR1E (0402); TLR2A (0805); TLR2B, TLR2BW, TLR2BP (1206); TLR2H and TLR2HW (2010); TLR3A, TLR3AW, TLR3AP, and TLR3APS(2512). These resistors use metal alloys to provide superior corrosion and heat resistance, operating temperatures from -65°C to +1 ...

2022-12 Semiconductors MaxLinear, Inc.

[Dec 23 2022] MaxLinear's 40v XR79203 and XR79206 synchronous step down COT power modules combine controller, driver, inductor, passive component, and mosfet into a simple and easy to use QFN package while providing high efficiency with a small footprint. Few external components are required, making design simple and time to market fast. All pins are easy to debug and wire, and the large pad provides high ther ...

2022-12 Semiconductors Texas Instruments

[Dec 23 2022] The Texas Instruments BQ500511 is a wireless power transmitter controller in a thermally-enhanced 6 mm x 6 mm, 40-pin VQFN package. When combined with the BQ50002 analog front-end device, all features needed to create a QI-compatible or proprietary 5v transmitter are integrated. BQ500511 and BQ50002 together provide a compact wireless charger solution. The BQ500511 pings the surrounding environme ...

2022-12 Semiconductors Texas Instruments

[Dec 22 2022] The CDCM6208V2G of Texas Instruments is a highly versatile, low jitter, low power clock generator that can generate eight low jitter clock outputs. It is one of the two inputs of optional LVPECL like high jitter CMLs, normal jitter CMLs, LVDS like low power consumption CMLs, HCSLs, or LVCMOS. These inputs can have low-frequency crystals, or CML, LVPECL, LVDS, or LVCMOS signals, for a variety of w ...

2022-12 Semiconductors Texas Instruments

[Dec 22 2022] The Texas Instruments BQ77915 is a low-power battery pack protector with voltage, current and temperature protection and does not require a microcontroller (MCU) controlled smart battery balancing algorithm. The device's stacking interface provides simple scaling to support battery cell applications from Series 3 to Series 20 or more. Protection thresholds and delays are factory programmed and av ...

2022-12 Power Teledyne LeCroy

[Dec 22 2022] Teledyne LeCroy Multi-channel programmable DC power supply T3X3200P series has a maximum power output of 217 W, including four models :T3PS13206P(0 to 32 V / 0 to 6 a) for single-channel output, and T3PS23203P for dual-channel output (CH1: 0-32 V / 0 to 3,CH2:0 32 V / 03 a), T3PS33203P three-channel output (CH1: 0-32 V / 0 to 3,CH2: 0-32 V / 0 to 3,CH3: 1.8V, 2.5V, 3.3V, 5.0V / 5 a), and a four-c ...

2022-12 Semiconductors Microchip Technology

[Dec 22 2022] Microchip Technology's ZL4029x series are high-performance ultra-low jitter low power 1 to 20 High speed current steering logic (HCSL) splitter buffers. ZL40292 and ZL40294 fully comply with DB2000Q and DB2000QL standards, while ZL40293 and ZL40295 are available for PCIe Gen 1, 2, 3 and 4 specifications. Each buffer is an ideal complement to chipsets that require distributed clocks across several ...

2022-12 Power Allegro MicroSystems, LLC

[Dec 22 2022] Allegro MicroSystems' A5976, A5977 and A5979 are complete microstepper motor driver chips with built-in converters. They are designed to run bipolar stepper motors in full, half, quarter, eight-step (A5977), and 16-step (A5976/79) modes, with an output drive capacity of 40 V±2.8 A. The A5977 and A5979 include a fixed turn-off time current regulator capable of operating in slow, fast, or mixed att ...

2022-12 Sensors Maxim Integrated

[Dec 22 2022] Maxim Integrated's MAX98360x is easy to use, low-cost, digital pulse Coded modulation (PCM) input Class d amplifier delivering Class ab audio performance and Class d efficiency. The digital audio interface automatically recognizes different PCM and time division multiplexing (TDM) clock schemes, thus eliminating the need for I(2)C programming. Simple power supply, LRCLK, BCLK, and digital audio t ...
