Technology Articles

2022-11 Semiconductors Toshiba Semiconductor and Storage

[Nov 26 2022] Toshiba TLP5212 IGBT gate Drive Optocoupler is an intelligent gate drive (SGD) coupler with IGBT desaturation detection, isolated fault state feedback, soft gate shutdown, active Miller clamp, and undervoltage latching (UVLO) functions. It is packaged with 10.3mm x 10.0mm x 2.1mm SO16L, and the operating temperature range is -40°C to +110°C. The device is designed to be used as a general purpose ...

2022-11 Semiconductors STMicroelectronics

[Nov 26 2022] The STMicroelectronics VIPERGAN65 HV converter is an advanced quasi-resonant offline HV converter with an E-mode GaN HEMT. The VIPERGAN65 is designed for use with medium-power quasi-resonant ZVS (zero voltage switch when switch on) flyback converters, providing up to 65W output power over a wide range. The VIPERGAN65 integrates a suite of features to provide an extremely flexible, easy-to-use chi ...

2022-11 Semiconductors ams

[Nov 25 2022] The ams OSRAM Mira220 1/2.7 2.2MP NIR enhanced Global shutter image sensor is designed for 2D and 3D consumer and industrial machine vision applications. Using advanced BSI technology, these sensors have a small pixel size of 2.79μm and high sensitivity. The series features 1600 (H) x 1400 (V) effective resolution and a 12-bit maximum bit depth, supporting external triggering, windowing, and on-c ...

2022-11 Semiconductors ams

[Nov 24 2022] Ams OSRAM AS7343L 13-channel multispectral sensor is designed for spectral recognition of lateral flow particle markers. Ultra-thin package with a size of 3.1mm x 2mm x 1mm. The AS7343L multifunctional sensor is ideal for supporting the latest laboratory applications. The device is optimized for reflection, transmission and radiation measurements. Applications include lateral flow test applicatio ...

2022-11 Semiconductors ams

[Nov 24 2022] The ams OSRAM AS7421 64-channel NIR sensor is designed for spectrum recognition and space occupancy area analysis in consumer devices. The spectral response of AS7421 provides a wavelength of 750nm to 1050nm and equally distributed channels over the entire range. At the beginning of spectral measurement, all 64 channels are automatically processed by 16 parallel sampling ADCs with four continuous ...

2022-11 Semiconductors Renesas Electronics America

[Nov 24 2022] Renesas Electronics RAA2S425x Automotive Sensor Signal conditioner optimized for automotive pressure sensing systems. The RAA2S425x device provides highly accurate amplification and sensor-specific correction of signals in automotive xEV, EV, and FCEV pressure-sensing braking, transmission, and HVAC systems. The RAA2S425x IC features highly integrated, advanced digital and analog capabilities tha ...

2022-11 Power Monolithic Power Systems Inc.

[Nov 24 2022] Monolithic Power Supply System (MPS) MPQ7235 Automotive infrared LED driver provides a high frequency, synchronous, rectifier, step-down, switching mode LED device with integrated power mosfet. The MPQ7235 is AEC-Q100 certified and comes in a space-saving QFN-13 (2.5mm x 3mm) package that requires a minimum number of standard external components. The MPQ7235 provides 1.5A continuous output curren ...

2022-11 Semiconductors Texas Instruments

[Nov 24 2022] The Texas Instruments DRV3256-Q1 Automotive Gate Driver Unit (GDU) is a highly integrated three-phase gate driver for 48V automotive motor drive applications. The device is specifically designed to provide A gate drive current of 2A peak pull current and 2.5A peak fill current, as well as a 90V MOSFET transient overvoltage support to support high-power motor drive applications. Efficient bootstra ...

2022-11 Semiconductors Texas Instruments

[Nov 23 2022] Texas Instruments DRV8300U Three-phase Gate drivers feature three half-bridge gate drivers with a voltage of 100V, each capable of driving both a high - and low-side n-channel power MOSFET. The DRV8300UD uses an integrated bootstrap diode and an external capacitor to generate the correct gate drive voltage for a high-side MOSFET. GVDD is used to generate a gate drive voltage for a low-side MOSFET ...

2022-11 Semiconductors Texas Instruments

[Nov 23 2022] Texas Instruments LMK5B33216 Network Synchronizer and jitter eliminator are designed to meet the rigorous requirements of Ethernet-based networking applications with timing accuracy. 5ns (class D). The network synchronizer integrates three DPLLS to provide interruption-free switching. It also has jitter attenuation, programmable loop bandwidth, and no external loop filter. This feature maximizes ...

2022-11 Semiconductors Texas Instruments

[Nov 23 2022] Texas Instruments ESD341 TVS ESD Protection diode is a TVS ESD protection diode for HDMI 1.4 circuit protection. The ESD341 has the highest ESD impact dissipation rating (level 4) specified in IEC61000-4-2 international standard. The device's IO capacitance is 0.66pF (typical value), enabling high-speed interface protection up to 3.4Gbps, including support for protocols such as HDMI 1.4b. Low dyn ...

2022-11 Semiconductors Texas Instruments

[Nov 23 2022] Texas Instruments TPS22811x Load switches are a highly integrated set of power distribution solutions in a small package. The device supports the use of a minimum number of external components to control and monitor the power rail. The output conversion rate and surge current can be adjusted using an external capacitor. If the input exceeds the adjustable overvoltage threshold, the load is protec ...
